a Transition settings/execution buttons (assignable
buttons)
You can assign functions, such as settings and execution,
f
or transitions in the Home > Setup > Panel > Module >
Button Assign menu (19104.21).
For details about assigning buttons, see “Assigning
Control Panel Buttons” (page 402).
The functions that can be assigned to the four buttons at
t
he top and the five buttons on the left are different.
Transition type selection buttons
The following functions can be assigned to both the four
bu
ttons at the top and the five buttons on the left.
Wipe direction selection buttons
The following functions can be assigned to the four
bu
ttons at the top only.
Transition/macro execution buttons
The following functions can be assigned to the five
bu
ttons on the left only.
Keyframe fader button
The following functions can be assigned to both the four
but
tons at the top and the five buttons on the left.
Pattern limit setting buttons
The following functions can be assigned to the four
but
tons at the top only.
Main/sub switching buttons (multi program 2
mod
e)
The following functions can be assigned to the four
but
tons at the top only.
b Display
Displays the transition rate.
Note
Function
name
Button
name
Description
Mix MIX Selects mix.
NAM NAM Selects NAM (non-additive mix).
Super Mix SUPER
MI
X
Selects super mix.
Preset
Co
lor Mix
PST
COLOR
MIX
Selects preset color mix.
Wipe WIPE Selects wipe.
DME Wipe DME
WIPE
Selects DME wipe.
FM 1&2
Cli
p to FM
15&16 Clip
FM1&2
CLIP to
FM
15&16
CLIP
Selects clip transition.
Function
name
Button
name
Description
Reverse REV When not lit, the wipe proceeds
in
the direction from black to
white of the pattern images,
shown in “Wipe Pattern List”
(page 491), or in the direction of
the arrows (normal).
When lit, the wipe proceeds in
the
opposite direction of normal
(reverse).
Normal/
Re
verse
NORM/
REV
The wipe direction alternates
between normal and reverse
after each transition.
Function
name
Button
name
Description
Take TAKE Executes an auto transition with
th
e set transition rate and
transition type.
During the transition, the button
is
lit amber.
Cut CUT Executes an immediate
tra
nsition.
Macro
Tak
e
MCRO
TAKE
Executes a macro.
Function
name
Button
name
Description
KF KF Uses the fader lever as a
ke
yframe fader.
Function
name
Button
name
Description
Limit Set LIMIT SET Sets the pattern limit.
Pattern
Lim
it
PTN LIMIT Enables the pattern limit.
Function
name
Button
name
Description
Main MAIN Switches operation to the
fu
nction on the main side in multi
program 2 mode.
Simultaneously pressing the
[SUB]
button activates both the
main and sub operations.
Sub SUB Switches operation to the
fu
nction on the sub side in multi
program 2 mode.
