Sony ICP-X1116 User Manual

40
c Operation buttons
d Num
eric keypad
Use to enter numeric values and to add an effect timeline/
snap
shot attribute. Entered numeric values appear on the
display.
It is also used to enter numeric values in conjunction with
set
ting parameters in the device control block, setting the
transition rate in the utility/shotbox control block, and
other tasks.
The [GPI ENBL] button function is not supported.
e Di
splay
The following information is displayed.
• Left-side display (lines 1 to 3) and right-side display
(l
ines 1 to 2):
Selected region names (reference region is highlighted)
• Right-side display (lines 3 to 4):
Register numbers, reference region name, numeric
val
ues entered in the numeric keypad, and other items
– ALL Select all regions
configured
beforehand
If you press the
[AL
L] button while
a region is
selected, all
regions are
deselected.
Button name Description
UNDO After recalling a register, returns to
the
state before the register was
recalled.
STORE STATS Lights up amber when an effect
tim
eline/snapshot/shotbox/macro
is saved in a register.
While the [STORE STATS] button
is
lit amber, you can press and
hold the [STORE STATS] button
and press the [UNDO] button to
return to the state before saving.
TC Switches to timecode input mode.
STORE Switches to the mode for saving an
eff
ect timeline/snapshot/shotbox/
macro.
In save mode, the [STORE] button
is
lit amber.
RCALL Switches to the mode for recalling
an
effect timeline/snapshot/
shotbox/macro.
In recall mode, the [RCALL] button
is
lit amber.
Button name Description
0 to 9 Enters numeric values.
. (period) • Enters a decimal point.
• In timecode input mode, “00” is
en
tered.
• In effect timeline operation mode
and snapshot operation mode,
use to search for an empty
register.
Function name Button name Description
+/–
EFF DISS
• Inverts the + (plus) and – (minus)
signs.
• In effect timeline operation mode
and
snapshot operation mode,
use to add the effect dissolve
attribute.
CLR
AUTO TRANS
• Deletes the entered numeric
va
lue.
• In snapshot operation mode,
use to add the auto transition
attribute.
TRIM
GPI ENBL
Use when entering difference
v
alues.
Enter a numeric value and press
t
he [TRIM] button to increase/
decrease a setting value.
ENTER • Confirms the entered numeric
va
lue.
• For a register number, executes
a register recall/save.
Note
Button name Description
