Edition
2018
Workshop Manual
PARK PRO 340 IX
Chapter
4 Hydraulic system
Page
54
A
6. Stop the pumping activities when the uid level
is almost on the line (A).
7. Start the engine and wait for it to idle. Gradually
pour uid into the reservoir and make sure that
the level is always on the mark.
8. Replace the cap on the uid reservoir and
close the bonnet.
B
CLOSED
(seen from below)
9. Stop the engine.
10. Close the valves (B) on the axles.
11. Start the engine.
12. Move the machine 8 - 10 metres forward and 8 - 10 metres in reverse. At the same time,
turn the steering wheel full on.
13. Lift and lower the accessories hydraulic lifting device 3 - 4 times.
14. Stop the machine and put the parking brake back on.
15. Open the bonnet.
16. Check the level in the reservoir and top up if necessary.
17. Once the operation has been completed, replace the cap on the uid reservoir and close
the bonnet.
4.8.4 Replacing the reservoir uid lter
B
C
A
A
1. Extract the lter unit (A) from the reservoir.
• Press on the lter sleeve and move it
in the direction indicated by the arrow.
• Extract the lter unit from the reservoir.
2. Take hold of the sleeve and the lter spring.
3. Extract the lter (B) from the sleeve.
4. Check that the rubber gasket (C) on the bottom
of the lter is intact. Replace if necessary.
5. Insert the new lter and spring in the sleeve.
Push the lter until it clicks into its seat in the
sleeve.
6. Replace the unit in the reservoir. The upper
section of the lter must be inserted securely
with a click in the groove on the upper part of
the reservoir.
