Adjustment Procedures
TDS7104 & TDS7054 Service Manual
5-9
n. Set the GPIB address for the remainder of the newly named devices to
the GPIB address of the Fluke 9500B (previously noted). The addresses
for all the devices are summarized in Table 5--5.
Table 5- 5: Setting the GPIB addresses
Device GPIB address
DUT1 1
SG1 Set each address to that of
FG1
the F luke 9500B
AUX1
PS1
PG1
RT1
o. When the setup is complete, click OK to close the dialog box.
Adjustment Program Installation
You must install the performance verification test program before you install the
adjustment program. If you have not already installed the performance verifica-
tion test program, see Test Program Installation on page 4--22 and do those steps
first.
Follow these steps to install the adjustment program on the instrument controller.
The same steps apply whether the instrument controller is a separate PC or the
PC that is built into the oscilloscope. If you are using the PC built into the
oscilloscope as the controller, this procedure assumes that the GPIB card and
accompanying controller software are already installed and configured as
necessary.
1. Locate the adjustment program: Locate the Adjustment Software CD that is
included with this manual and insert it into the disk drive on the instrument
controller.
2. Start the installation wizard: Select Run...in the Start menu and then
enter D:\adjsetup.exe.
3. Follow the instructions: Follow the instructions presented by the installation
wizard to install the adjustment program.
