Tektronix TDS6000 Series Service Manual

Specifications
TDS7104 & TDS7054 Service Manual
1-21
Table 1- 11: Certifications and compliances
Category Standards or description
EC Decl aration of Conformity --
EMC
Meets int ent of Directive 89/336/EEC for Electromagnetic Compatibility. Compliance was
demonstrated to the following specifications as listed in the Official Journal of the European Union:
EN 61326 Emissions
1, 3
Class A Radiated and Conducted Emissions
EN 61326 Immunity
1
,
2
,4
IEC 1000-4-2 Electrostatic Discharge Immunity
±4 kV contact discharge, ±8 kV air di scharge,
performance criterion B
IEC 1000-4-3 RF field immunity
3V/m,80MHzto1GHz,
80% ampli tude m odulated with a 1 kHz sinewave
performance criterion A
IEC 1000-4-4 Electrical Fast Transient/Burst Immunity
1 kV on AC mains, 500 V on I/O cables, performance criterion B
IEC 1000-4-5 AC Surge Immunity
1 kV differential mode, 2 kV common mode,
performance criterion B
IEC 1000-4-6 RF Conducted I mmunity
3 V, 150 kHz to 80 MHz, amplitude modulated with a
1 kHz sinewave, performance criterion A
IEC 1000-4-11 AC M ains Voltage Dips and Interruption Immunity
100% reduction for one cycle, performance criterion B
EN 61000-3-2 Power Harmonic Current Emissions
1
If int erconnect cables are used, they must be low-EMI shielded cables such as the following
Tekt ronix part numbers or their equivalents: 012-0991-01, 012-0991-02 or 012-0991-03 GPIB
Cable; 012-1213-00 (or CA part number 0294-9) RS-232 Cable; 012-1214-00 Centronics
Cable; or LCOM part number CTL3VGAMM-5 VGA Cable.
2
The performance criteria for when the instrument is subjected to the conditions described
above are def ined as follows:
A — ≤0. 2 division waveform displacement or ≤0.4 division increase in peak-to-peak noise
B — temporary, self-recoverable degradation or loss of performance is allowed, but no change
of actual operating state or loss of stored data is allowed
C — temporary loss of function is allowed provided that the function is self recoverable or can
be restored by the operation of the controls
3
Radiated emi ssions may exceed the levels specified in EN 61326 when this instrument is
connected to a test object.
4
USB mouse and keyboard only, performance criterion C. Normal USB keyboard or mouse
operation can be restored by unplugging and reconnecting the USB connector t o the
instrument.
FCC Radiated and conducted emissions do not exceed the levels specified in FCC47 CFR, Part 15,
Subpart B, for Class A equipment.
