Specifications
1-10
TDS7104 & TDS7054 Service Manual
Table 1- 3: Horizontal and acquisition system specifications
Characteristic Description
Acquisition modes Sample, Peak detect, Hi Res, Average, Envelope, and
Waveform dat abase
Acquisition rate up t o 200,000 waveforms per second in Fast Acquisition
mode
up t o 130 wavef orm s per second with Fast Acquisition off
Minimum record length 500 points
Maximum record l ength Depends on the number of active channels and the record
length options installed
Standard 500,000 points (3 or 4 channels)
1,000,000 points (1 or 2 channels only)
2,000,000 points (1 channel only)
Option 2M installed 2,000,000 points (3 or 4 channels)
4,000,000 points (1 or 2 channels only)
8,000,000 points (1 channel only)
Option 3M installed 4,000,000 points (3 or 4 channels)
8,000,000 points (1 or 2 channels only)
16,000,000 points (1 channel only)
Real-time sample rate range Number of channels
acquired
Sample rate range
TDS7054 1 1.25 S/s to 5 GS/s
2 1.25 S/s to 5 GS/s
3or4 1.25 S/s to 2.5 GS/s
TDS7104 1 1.25 S/ s to 10 GS/s
2 1.25 S/s to 5 GS/s
3or4 1.25 S/s to 2.5 GS/s
Equivalent-time sample rate or
interpolated waveform rate range
5 GS/ s to 250 GS/s
Equivalent-tim e acquisi tion can be enabled or disabled.
When disabled, waveforms are interpolated at the fastest
time base settings.
Seconds/division range 200 ps/ div to 40 s/div
Horizontal delay range 0 s to 1000 s
