Tektronix TDS6000 Series Service Manual

Performance Tests — Semi-Automated Method
TDS7104 & TDS7054 Service Manual
4-25
TDS7000 oscilloscope
BNC cable from PROBE
COMPENSATION output
to CH 1 input
Figure 4- 11: Setup to check probe compensation output
TDS7000 oscilloscope
BNC cable from SIGNAL
OUT to CH 1 input
Figure 4- 12: Setup to check analog signal output
TDS7000 oscilloscope
BNC cable from AUX OUT
to CH 1 input
Figure 4- 13: Setup to check auxiliary output
