Toro Dingo TX 413 User Manual

Rev. 000
Figure 461 DSC-0827
Figure 460 DSC-0824
DRIVE SYSTEM
8-12
TX 413 Service Manual
5. Press bearing out from the seal side, pressing on
the inner race of the bearing (Fig. 461).
4. Remove the road wheel from the track guide (Fig.
460).
2. Remove wheel bearing cap with seal (Fig. 458).
Figure 458 DSC-0822
Figure 459 DSC-0823
3. With a ratchet and socket, remove bolt retaining
the road wheel (Fig. 459).

Toro Dingo TX 413 Specifications

General

Brand	Toro
Model	Dingo TX 413
Category	Compact Loader
Language	English
