TX 413 Service Manual
5-9
ELECTRICAL SYSTEM
Electrical Schematic Wiring Diagram
X I Y S B A
SW4
IGNITION SWITCH
X
Y
A
S
B
I
PN 88-9830
OFF = no connections
= B I S
ON
= B I A and X Y
START
Ignition switch terminal
Locations viewed from back
PK PK BN GN
R
VIO
B
A
VIO
BK
OPTIONAL HEADLIGHTS
F3
10A
HOUR METER
+
_
BK
F2
25 A
VIO
AC
AC
F4
10 A
PK
GN
GN
GN
T BU
K2
START
RELAY
R
F1
30 A
R
IGNITION
MODULE
GY
GY
SW2
NEUTRAL
CLOSED WHEN
IN NEUTRAL
FUEL SOLENOID
SW5
DETENT
CLOSED WHEN
OUT OF DETENT
K1
KILL RELAY
BN
W
Y
BK
BK
1
2
3
4
5
1 2
3
4
5
BK
W
BK/Y
GY
W/BU
GY
GND
REG. DC
B+
AC
CHARGE LAMP
AC
VOLTAGE
REGULATOR
NOTE: SOME WIRE COLORS CHANGE
AT REGULATOR CONNECTOR
BK
GND
MAGNETO
W
BU
R
SPARK
PLUG
W
+
_
B
ST
OIL SWITCH
CLOSES WHEN
OIL IS LOW
STARTER
<
<
<
<
<
<
WIRE COLOR CODES
BK – BLACK PK – PINK
BN – BROWN R – RED
BU – BLUE T – TAN
GN – GREEN VIO – VIOLET
GY – GREY W – WHITE
OR – ORANGE Y – YELLOW
BK/Y – BLACK/YELLOW W/BU – WHITE/BLUE
