1-17
7. Install the element.
Install the evacuator valve in the illustrated direction.
CLOGGING WARNING SYSTEM
INSPECTION (OPT)
1. Warning lamp inspection
(1) Check that the air cleaner warning lamp comes on when
the ignition key switch is turned ON and goes out when
the engine starts.
2. Individual inspection
(1) Use a mity vac to apply a negative pressure to the
vacuum switch, and inspect for continuity.
Standard
4Y engine vehicle
2630~3218 Pa (270~330 mmAq) (19.9~24.3 mmHg):
continuity exists
1DZ-II engine vehicles
6904~8042 Pa (704~820 mmAq) (51.7~60.3 mmHg):
continuity exists
25°
Engine
Section 1

Toyota 8FGU25 Specifications

General

Model	8FGU25
Lift Height	189 inches
Tire Type	Pneumatic
Transmission	Automatic
Engine Type	Internal Combustion
Load Capacity	5000 lbs
Fuel Type	Gasoline or LPG
Mast Type	2-Stage
Overall Width	45.3 in (1150 mm)
Wheelbase	63 in (1600 mm)
