2. How to read components figures
(1) The components figure uses the illustration in the
parts catalog for the vehicle model. Please refer
to the catalog for checking the part name.
The number at the right shoulder of each
components figure indicates the Fig. number in
the parts catalog.
3. Matters omitted in this manual
(1) This manual omits description of the following jobs, but perform them in actual operation:
(a) Cleaning and washing of removed parts as required
(b) Visual inspection (partially described)
TERMINOLOGY
Caution:
Important matters of which negligence may cause hazards on human body. Be sure to observe them.
Note:
Important items of which negligence may cause breakage or breakdown, or matters in operation procedure
requiring special attention.
Standard: Values showing allowable range in inspection and adjustment.
Limit: Maximum or minimum allowable value in inspection or adjustment.
ABBREVIATIONS
Abbreviation (code) Meaning Abbreviation (code) Meaning
ASC Auto Speed Control R/B Relay block
ATT Attachment RH Right hand
Cu Cushion tire models RR Rear
FR Front
SAE
Society of Automotive
Engineers (USA)
J/B Junction block
ASSY Assembly SAS System of active stability
LH Left hand SOL Solenoid
LLC Long life coolant SST Special service tool
M/T Manual transmission STD Standard
NMR No-load maximum speed T = Tightening torque
OPS Operator Presence Sensing
T/C
Torque converter &
transmission
OPT Option
O/S Oversize c c T Number of teeth (c c)
Pn Pneumatic tire models U/S Undersize
PS Power steering W/ With
QFV 4-stage mast (Quadruple) L/ Less
(Example)
3201
FIG number in parts catalog
