TP-Link TL-WA7210N User Manual

TL-WA7210N
2.4GHz 150Mbps Outdoor Wireless Access Point User Guide
111
4. In Domain Name field, enter www.google.com.
5. Click Save to complete the settings.
6. Go back to the Target Settings page and see the following list
Figure 5-53 Access Target List
Click the Add New... button to add a new target entry.
Click the Delete All button to delete all the entries in the table.
Click the Next button to go to the next page.
Click the Previous button return to the previous page.
5.12.4 Schedule
Choose menu Access Control > Schedule, you can view and set a Schedule list in the next
screen as shown in Figure 5-54. The Schedule list is necessary for the Access Control Rule.
Figure 5-54 Schedule Settings
 Schedule Description - Here displays the description of the schedule and this description is
unique.
 Day - Here displays the day(s) in a week.
 Time - Here displays the time period in a day.
 Modify - Here you can edit or delete an existing schedule.
 For example: If you desire to restrict the Internet activities of host with MAC address
00-11-22-33-44-AA to access www.google.com only from 18:00 to 20:00 on Saturday and
Sunday, you should first follow the settings below:
1. Click Add New... button to enter the Advance Schedule Settings page.
2. In Schedule Description field, create a unique description for the schedule, for example
Schedule_1.
3. In Day field, choose Select Days and select Sat and Sun.
4. In Time field, enter 1800 in Start Time and 2000 in Stop Time.
5. Click Save to complete the settings.
6. Go back to the Schedule Settings page and see the following list

TP-Link TL-WA7210N Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab
Receiver sensitivity	802.11n\\r 150M: -76dBm\\r 121.5M: -78dBm\\r 108M: -80dBm\\r 81M: -84dBm\\r 54M:-87dBm\\r 40.5M:-91dBm\\r 27M:-92dBm\\r 13.5M:-95dBm\\r 802.11g\\r 54M: -79dBm\\r 48M: -81dBm\\r 36M: -85dBm\\r 12M: -92dBm\\r 6M:-95dBm
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	150 Mbit/s
Maximum operating distance	150 m
Internal	No
Certification	CE, FCC, RoHS
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 70 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Input current	1 A
AC input voltage	12 V
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7/8, MAC OS, NetWare, UNIX, Linux
Antenna gain level (max)	12 dBi

Weight and Dimensions

Depth	120 mm
Width	265 mm
Height	83 mm
