TL-WA7210N
2.4GHz 150Mbps Outdoor Wireless Access Point User Guide
115
 Description - The information of description include address range, the port range and
protocol of transport layer.
 Egress Bandwidth - The max upload speed which through the WAN port. The default
number is 0.
 Ingress Bandwidth - The max download speed which through the WAN port. The default
number is 0.
 Enable - Rule status, which shows whether the rule takes effect.
 Modify - Choose to modify or delete an existing entry.
5.15 IP & MAC Binding
ARP Binding is useful for controlling access of specific computers in the LAN. This page displays
the IP & MAC Binding Setting table; you can operate it in accord with your desire.
There are two submenus under the IP & MAC Binding menu (shown in Figure 5-63): Binding
Setting and ARP List. Click any of them, and you will be able to configure the corresponding
function. The detailed explanations for each submenu are provided below.
Figure 5-63 the IP & MAC Binding menu
5.15.1 Binding Setting
Selecting IP & MAC Binding > Binding Setting will allow you to configure the binding entries, as
shown in Figure 5-64.
Figure 5-64 Binding Setting
 MAC Address - The MAC address of the controlled computer in the LAN.
 IP Address - The assigned IP address of the controlled computer in the LAN.
 Bind - Check this option to enable ARP binding for a specific device.
 Modify - To modify or delete an existing entry.
When you want to add or modify an IP & MAC Binding entry, you can click the Add New button
or Modify button, and then you will go to the next page. This page is used for adding or
modifying an IP & MAC Binding entry
(shown in Figure 5-65).

TP-Link TL-WA7210N Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab
Receiver sensitivity	802.11n\\r 150M: -76dBm\\r 121.5M: -78dBm\\r 108M: -80dBm\\r 81M: -84dBm\\r 54M:-87dBm\\r 40.5M:-91dBm\\r 27M:-92dBm\\r 13.5M:-95dBm\\r 802.11g\\r 54M: -79dBm\\r 48M: -81dBm\\r 36M: -85dBm\\r 12M: -92dBm\\r 6M:-95dBm
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	150 Mbit/s
Maximum operating distance	150 m
Internal	No
Certification	CE, FCC, RoHS
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 70 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Input current	1 A
AC input voltage	12 V
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7/8, MAC OS, NetWare, UNIX, Linux
Antenna gain level (max)	12 dBi

Weight and Dimensions

Depth	120 mm
Width	265 mm
Height	83 mm
