Triumph Scrambler 900 User Manual

MAINTENANCE AND ADJUSTMENT
102
Caution
If the engine oil pressure is too low,
the low oil pressure warning light will
illuminate. If this light stays on when
the engine is running, stop the engine
immediately and investigate the cause.
Running the engine with low oil
pressure will cause engine damage.
▼ Turn the ignition OFF, check the
engine oil level using the method
previously described, and top off
to between the minimum and
maximum level lines in the sight
glass.
Disposal of Used Engine Oil and Oil
Filters
To protect the environment, do not
pour oil on the ground, down sewers or
drains, or into groundwater sources.
Do not place used oil filters in with
general waste. If in doubt, contact your
local authority.
Engine Oil Specification and Grade
(10W/40 & 10W/50)
Triumph's high performance fuel
injected engines are designed to
use 10W/40 or 10W/50 semi or fully
synthetic motorcycle engine oil that
meets specification API SH (or higher)
and JASO MA, such as Castrol Power
1 Racing 4T 10W-40 (fully synthetic)
engine oil, sold as Castrol Power RS
Racing 4T 10W-40 (fully synthetic) in
some countries.
Refer to the chart below for the correct
oil viscosity (10W/40 or 10W/50) to be
used in your riding area.
-20 -10 0 10 20 30 40
-4 14 5032 68 86 104
(°C)
(°F)
Ambient Temperature (°C)
Ambient Temperature (°F)
SAE 10W/50
SAE 10W/40
Oil Viscosity Temperature Range
Do not add any chemical additives
to the engine oil. The engine oil also
lubricates the clutch and any additives
could cause the clutch to slip.
Do not use mineral, vegetable, non-
detergent oil, castor based oils or any
oil not conforming to the required
specification. The use of these oils may
cause instant, severe engine damage.
Make sure that no foreign matter enters
the crankcase during an engine oil
change or top off.

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
