GENERAL INFORMATION
39
If the warning light becomes
illuminated while riding, it indicates
that the traction control system has a
malfunction that requires investigation.
Turn Signals
When the turn signal switch is
turned to the left or right, the
indicator warning light will
flash on and off at the same
speed as the turn signals.
High Beam
When the ignition is switched
ON and the high beam is
selected, the high beam
warning light will illuminate.
Daytime Running Lights (DRL)
(if equipped)
When the ignition is switched
ON and the daytime running
lights switch is set to Daytime
Running Lights, the daytime
running lights warning light will
illuminate. During daylight hours, the
Daytime Running Lights (DRL) improve
the visibility of the motorcycle to other
road users. Low beam headlights must
be used in any other conditions unless
the road conditions allow for high beam
headlights to be used.
The daytime running lights and low
beam headlights are operated manually
using a switch on the left hand switch
housing, see page 39.
Warning
Do not ride for longer than necessary
in poor ambient light conditions with
the Daytime Running Lights (DRL) in
use.
Riding with the Daytime Running
Lights when dark, in tunnels or where
poor ambient light is apparent may
reduce the riders vision or blind other
road users.
Blinding other road users or reduced
vision in low ambient light levels may
result in loss of motorcycle control and
an accident.
Neutral
The neutral warning light
indicates when the
transmission is in neutral (no
gear selected). The warning
light will illuminate when the
transmission is in neutral with the
ignition switch in the ON position.
Low Fuel Indicator Light
The low fuel indicator light will
illuminate when there is
approximately 0.8 gallon
(3 liters) of fuel remaining in
the tank.

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
