WARRANTY
168
To obtain reimbursement from Triumph
Motorcycles America Limited for such
emergency repairs, you must keep
all failed parts and original receipts,
marked "paid," so you can present them
to an authorized Triumph dealer for
their inspection. Triumph Motorcycles
America Limited recommends that you
bring your motorcycle to an authorized
dealer for inspection to ensure that the
emergency repairs were done properly.
What is Covered by this
Emission Warranty
The emission control system warranty
covers the following "warranted parts"
only:
▼ Fuel injection/engine management
equipment including oxygen sensors
▼ Intake manifold
▼ Air cleaner box
▼ Spark advance/retard system
▼ Spark plugs (first 10,000 miles)
▼ Ignition coils
▼ Charcoal canister
▼ Cap, fuel tank
▼ Fuel/vapor separator (fuel tank)
▼ Vapor valve
▼ Rollover/pressure control valves
▼ If used on the above systems: hoses,
clamps, fittings, tubing, sealing
gaskets and mounting hardware.

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
