Triumph Scrambler 900 User Manual

MAINTENANCE AND ADJUSTMENT
141
▼ Install new ECM fasteners to secure
the ECM unit. Tighten to 89 lbf in
(10 Nm).
▼ Reconnect the three connectors to
the ECM unit.
▼ Reconnect the accessory connector.
Secure the accessory connector
cable into the ECM cable clips.
▼ Reconnect the battery, positive (red)
lead first and then the negative
(black) lead.
▼ Tighten the battery terminals to
40 lbf in (4.5 Nm).
▼ Apply a light coat of grease to the
terminals to prevent corrosion.
▼ Cover the positive terminal with the
protective cap.
▼ Reinstall the seat (see page 71).
Speed Twin 1200 and Thruxton RS Only
To install the battery:
▼ Place the battery in the battery
case.
▼ Secure with the battery strap and
make sure the USB port socket is
reinstalled.
▼ Reconnect the battery, positive (red)
lead first and then the negative
(black) lead.
▼ Tighten the battery terminals to
40 lbf in (4.5 Nm).
▼ Apply a light coat of grease to the
terminals to prevent corrosion.
▼ Cover the positive terminal with the
protective cap.
▼ Reinstall the seat (see page 71).
Fuses
Warning
Always replace blown fuses with new
ones of the correct rating (as specified
on the fuse box cover).
Never replace a blown fuse with a fuse
of a different rating.
Use of an incorrect fuse could lead
to an electrical problem, resulting in
motorcycle damage, loss of motorcycle
control and an accident.
Note
A blown fuse is indicated when all of the
systems protected by that fuse become
inoperative. When checking for a blown
fuse, use the table to establish which
fuse has blown.

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
