Triumph Scrambler 900 User Manual

SPECIFICATIONS
188
Thruxton RS
Dimensions, Weights and Performance
A list of model specific dimensions, weights and performance figures is available
from your authorized Triumph dealer, or on the Internet at www. triumph. co. uk.
Payload Thruxton RS
Maximum Payload 463 lb (210 kg)
Engine Thruxton RS
Type Liquid cooled parallel twin, 270° firing angle
Displacement 73.2 cu in (1200 cc)
Bore x Stroke 3.84 x 3.15 in (97.6 x 80 mm)
Compression Ratio 12.066:1
Cylinder Numbering Left to right
Cylinder Sequence 1-2
Firing Order 1-2
Starting System Electric starter
Lubrication Thruxton RS
Lubrication System Wet sump
Engine Oil Capacities:
Dry Fill 1 gallon (3.8 liters)
Oil/Filter Change 0.9 gallon (3.4 liters)
Oil Change Only 0.85 gallon (3.2 liters)
Cooling Thruxton RS
Coolant Type Triumph HD4X Hybrid OAT
Water/Coolant Ratio 50/50 (pre-mixed as supplied by Triumph)
Coolant Capacity 0.41 gallon (1.558 liters)
Thermostat Opens 167°F (75°C) +/- 35°F (2°C)

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
