Triumph Scrambler 900 User Manual

GENERAL INFORMATION
67
Whenever the side stand is used, before
riding, always make sure that the stand
is fully up after first sitting on the
motorcycle.
For instructions on safe parking, refer
to the 'How to Ride the Motorcycle'
section.
Center Stand (if equipped)
Caution
Do not use body panels or the seat
as a handhold when placing the
motorcycle on the center stand as this
will cause damage.
1
1. Center stand
To set the motorcycle on the center
stand:
▼ Hold the motorcycle upright.
▼ Step down firmly on the foot finder
part of the stand.
▼ Lift the motorcycle up and to the
rear using the rear frame as a
handhold.
For instructions on safe parking, refer
to the How to Ride the Motorcycle
section.

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
