Triumph Scrambler 900 User Manual

MAINTENANCE AND ADJUSTMENT
128
Rear Suspension
Caution
The rear suspension units on the
Thruxton RS are equipped with a
protective film label. This protective
film label will gradually wear. This wear
is normal and not considered to be a
fault. It does not affect the safety,
operation or performance of the rear
suspension.
If the motorcycle is used in dirty
or dusty environments, the wear
on the protective film labels will be
accelerated.
To reduce the wear on the protective
film labels, dirt should be washed from
between them after use in dirty or
dusty environments.
The protective film labels are
replaceable and can be replaced by an
authorized Triumph dealer.
The Thruxton RS suspension has three
different rear adjustment settings;
spring preload, rebound damping and
compression damping. All other models
only have adjustable spring preload
settings.
The Standard rear suspension preload
settings provide a comfortable ride
and good handling characteristics
for general, solo riding. The following
tables show suggested settings for
rear suspension under different load
conditions for all models.
Rear Suspension Settings
The details shown in the tables are only
a guide. Setting requirements may vary
for rider and passenger weight and
personal preferences.
All Models except Speed Twin 1200 and
Thruxton RS
All Models except Speed Twin 1200 and
Thruxton RS Rear Suspension Settings
Loading
Spring
Preload
1
Solo Riding - Standard 1
Rider, Passenger and Luggage 5
1
Position 1 is minimum (fully clockwise) and
position 3 is maximum (fully counterclockwise).
Speed Twin 1200 Only
Speed Twin 1200 Rear Suspension Settings
Loading
Spring
Preload
1
Solo Riding - Standard 2
Rider, Passenger and Luggage 5
1
Position 1 is minimum (fully clockwise) and
position 3 is maximum (fully counterclockwise).
Thruxton RS Only
Thruxton RS Rear Suspension Settings
Loading
Spring
Preload
1
Rebound
Damping
2
Com-
pression
Damping
2
Solo Riding -
Standard
1 24 16
Solo Riding -
Comfort (Softer)
1 44 20
Solo Riding -
Sport (Firmer)
1 12 8
Rider and
Passenger
3 15 10
1
Position 1 is minimum (fully clockwise) and
position 3 is maximum (fully counterclockwise).
2
Number of clicks counterclockwise from the
fully clockwise position noting that the first stop
(click) is counted as one.

Triumph Scrambler 900 Specifications

General

Displacement	900 cc
Max Torque	80 Nm @ 3, 250 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel, with twin cradles
Seat Height	790 mm
Bore x Stroke	84.6 mm x 80 mm
Clutch	Wet, multi-plate assist clutch
Swingarm	Twin-sided, tubular steel
Front Tyre	100/90-19
Rear Tyre	150/70 R17
Rake	25.8°
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS / 64 bhp (47.8 kW) @ 7, 250 rpm
Exhaust	Stainless steel 2-into-2 exhaust system with twin silencers
Front Suspension	41 mm telescopic forks, 120 mm travel
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Single 310 mm disc, Brembo 4-piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Front Wheel	19 x 2.5 in
Rear Wheel	17 x 4.25 in
Fuel Tank Capacity	12 L
Instrument Display	LCD multi-functional instrument pack with analogue speedometer
Length	2, 125 mm
