Triumph Tiger Sport User Manual

Maintenance and Adjustment
128
Licence Plate Light
Bulb Replacement
To replace the licence plate bulb:
Remove the seat (see page 62).
Disconnect the battery, negative (black)
lead first.
Remove the licence plate.
Remove the two lower rear mudguard
fixings.
1. Rear mudguard
2. Fixings
Gently pull the mudguard rearwards to
allow access to the licence plate light
retaining nut.
Counter hold the nut to prevent it from
turning and remove the licence plate
light fixing screw. Collect the nut from
the mudguard.
1. Screw
2. Licence plate light fixing nut
3. Rear mudguard
Detach the licence plate light from the
rear mudguard.
Caution
Do not pull the rear mudguard more
than is necessary to access the
licence plate light's inside fixing nut.
Damage to the rear mudguard will
result from bending the mudguard too
far.
chwy
2
1
Caution
To avoid cable damage, do not pull the
bulb holder using the cables. Pull only
on the bulb holder.
chww
1
2
3

Triumph Tiger Sport Specifications

General

Transmission	6-speed
Seat Height	830 mm (32.7 in)
Tires Front	120/70 ZR17
Tires Rear	180/55 ZR17
Fuel Tank Capacity	20 L (5.3 US gal)
Fuel System	Fuel injection
Front Brakes	Twin 320 mm floating discs, Brembo 4-piston radial calipers, ABS
Rear Brakes	Single 255mm disc, ABS
