General Information
45
TPMS Sensor ID Number
An ID number for each tyre pressure
sensor is printed on a label which is on
the sensor. This number may be
required by the dealer for service or
diagnostics.
If the TPMS has been fitted at the
factory, labels identifying the front and
rear TPMS sensor ID numbers is affixed
to the spaces below.
If the TPMS is being fitted to the
motorcycle as an accessory, make sure
that the dealer records the front and
rear TPMS sensor ID numbers in the
spaces provided below.
System Display
1. TPMS symbol
2. Front tyre, identified
3. Rear tyre, identified
4. Tyre pressure display
To access the tyre pressure display:
Make sure the motorcycle is stationary.
Turn the ignition switch to the ON
position.
Press and release the SET button on the
left handlebar switch housing until 'InFo’
is shown.
Press and release the SCROLL button to
select the front or rear tyre pressure.
When the TPMS has been selected, '--'
'PSI' or 'bAr' is shown in the display
screen until the motorcycle is travelling
at a speed greater than 12 mph
(20 km/h) and the tyre pressure signal is
received.
To exit the tyre pressure display:
Press and release the HOME button until
the journey distance in trip 1 menu is
shown.
