General Information
29
Speedometer and Odometer
The digital speedometer indicates the
road speed of the motorcycle. The
display shows the motorcycle road
speed in increments of one mile (or
kilometre) per hour.
The electronic odometer and two trip
meters are in the display screen.
Tachometer
The tachometer shows the engine speed
in revolutions per minute - rpm (r/min).
At the end of the tachometer range
there is the 'red zone'. Engine speeds in
the red zone are above maximum
recommended engine speed and are also
above the range for best performance.
Trip Computer
1. SCROLL button, up
2. SCROLL button, down
3. SET button
To access the trip computer information:
Make sure the motorcycle is stationary.
Turn the ignition switch to the ON
position.
Press and release the SET button on the
left handlebar switch housing until the
desired display is shown.
The display will scroll through in the
following order:
•Trip Meter1
•Trip Meter2
• InFo menu
•Set up menu.
