General Information
54
Direction Indicator Switch
When the indicator switch is pushed to
the left or right and released, the
corresponding direction indicators will
flash on and off.
1. Direction indicator switch
The indicator self-cancel system
becomes active after operating a
direction indicator.
Eight seconds after turning the direction
indicator on and after riding a further
65 metres, the indicator self-cancel
system automatically turns off the
indicators.
The indicators can be cancelled
manually. To manually turn off the
indicators, press and release the
indicator switch in the central position.
To disable the indicator self-cancel
system see page 40.
Horn Button
When the horn button is pushed, with
the ignition switch turned to the ON
position, the horn will sound.
1. Horn button
SCROLL Button
When the SCROLL button is pressed and
released, it scrolls through the menu
shown in the display screen.
1. SCROLL button, up
2. SCROLL button, down
To Next Page
