BA 50Z3/6003 en – Edition 4.3 * 5003b330.fm 3-65
Operation
3.41 Raising/lowering the cab
Careful when raising or lowering the cab –
Risk of accidents.
☞ Always tighten lock nuts A and C when operating the machine.
☞ Place the machine on level ground.
☞ Lower the boom and the stabilizer blade.
☞ Stay clear from underneath the cab as you raise or lower it.
Always lock the door:
Risk of accidents.
☞ Always close and lock the door when tilting the cab.
☞ Remove loose objects from the cab.
Preparations for raising or lowering the cab:
☞ Stop the engine.
☞ Remove the ignition key and carry it with you.
☞ Raise the control lever base (left).
Slackening the securing elements:
☞ Raise the floor mat.
☞ Remove lock nuts A and C with a suitable tool.
➥ Lock nut A is located at the front right of the cab.
➥ Lock nut C is located at the rear right of the cab.
Fig. 145: Front lock nut
A
