6-24 BA 50Z3/6003 en – Edition 4.3 * * 5003b610.fm
Specifications
6.25 Lift capacity table 50Z3 VDS short stick, counterweight (option)
All table indications in kg (lbs) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The machine’s lift capacity is restricted by the settings of the pressure limiting valves and
the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
5.0 m (16'-5") 4.0 m (13'-1") 3.0 m (9'-10") 2.0 (78.7 in)
B\A
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
3.0 m
(9'-10")
1018*
(2245*)
669
(1475)
744
(1640)
965*
(2128*)
894
(1971)
965*
(2128*)
2.0 (78.7
in)
1049*
(2313*)
585
(1290)
650
(1433)
1048*
(2311*)
601
(1325)
669
(1475)
1155*
(2547*)
856
(1887)
957
(2110)
1501*
(3310*)
1328
(2928)
1501*
(3310*)
1.0 m
(39.4 in)
1095*
(2414*)
558
(1230)
621
(1369)
1122*
(2474*)
584
(1288)
651
(1435)
1406*
(3100*)
808
(1782)
907
(2000)
2196*
(4841*)
1209
(2666)
1384
(3052)
0.0 m
(0.0 in)
1153*
(2542*)
577
(1272)
644
(1420)
1563*
(3446*)
776
(1711)
873
(1925)
2459*
(5421*)
1158
(2553)
1330
(2933)
−1.0 m
(−39.4 in)
1218*
(2685*)
663
(1462)
742
(1636)
1511*
(3331*)
771
(1700)
868
(1914)
2329*
(5134*)
1156
(2549)
1328
(2928)
4357*
(9607*)
2260
(4983)
2752
(5671)
−2.0 m
(−78.7 in)
1258*
(2773*)
942
(2077)
1065
(2348)
1738*
(3832)
1193
(2631)
1368
(3016)
3075*
(6780*)
2326
(5129)
2828
(6236)
Fig. 338: Lift capacity table (model 50Z3)
max Admissible load on extended stick
A Reach
B Load hook height
* Lift capacity limited by hydraulic system
With the stabilizer blade in driving direction
Without the stabilizer blade, 90° to driving direction
