WinGD X62DF-S2.0 User Manual

Marine Installation Manual 2022-03 7-10
7 Engine Emissions
7.2 Engine noise
X62DF-S2.0
7.2.3 Structure-borne noise
The vibrational energy is propagated via engine structure, bedplate flanges and
engine foundation to the ship’s structure, which starts to vibrate and thus emits
noise.
The sound pressure levels in the accommodations can be estimated with the aid
of standard empirical formulas and the vibration velocity levels.
Figure 7-7 Structure-borne noise level at engine feet vertical
SM-0807
31.5 63 125 250 500 1k 2k 4k 8k
100
90
80
70
60
50
40
30
Octave band centre frequency in [Hz]
16k
Lv, re 5E-8 m/s [d/B]
Structure borne noise level Lv in dB at nominal MCR
8X62DF-S2.0
5X62DF-S2.0
