Xerox Phaser 6125 Service Manual

5-56 Phaser 6125/6130 Color Laser Printer Service Manual
Print-Quality Troubleshooting
19 Replace the Feed Roller (page 8-30).
Is the image printed correctly?
Complete Go to step 20.
20 NOTE: During this check, defeat the
Front Cover interlock switch (HARN
ASSY INTERLOCK).
1.Start the Main Motor FULL2 test:
Service Mode > Engine Diag >
Motor Test > Main Motor FULL2.
2.While it is running, start the Regi
Clutch test: Service Mode > Engine
Diag > Motor Test > Regi Clutch.
Do the Regi Roller Assy and Metal
Regi Roller rotate?
Complete Replace the
Feeder
Assembly
page 8-25.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
