• Adjust the image in the following order: Registration, Perpendicularity, Skew, and
Magnification.
• Choose only one option at a time (such as Registration), then run a set of test prints to
evaluate the output. Determine if the printed output for the selected option is acceptable
and if it is acceptable, then select and adjust the next alignment option.
• After each option is selected, always run a set of test prints and evaluate the output.
Determine if the output for the selected feature is acceptable. If it is, continue to adjust
another alignment option as required.
• To use an existing Alignment Profile, perform the following:
Note: The option may be found by selecting Machine Status→Tools→Setup &
Adjustment→Alignment Adjustment Setup. Select the desired Custom
Paper→Change Settings→Alignment Adjustment Setup→Change Settings.
a. Select the Alignment Adjustment button.
b. Select Use Default or Select from List.
If using Select from List, make a selection from the list of saved Alignment Profiles.
3. Change the Adjust Regi-Loop setting.
Note: Use Adjust Regi-Loop only if Alignment Adjustment did not correct registration
and/or skew problems.
• Use this feature to adjust Regi-Loop.
• When paper feeds through the press, it stops once and pressure is applied in order to correct
registration and skew. The loop is created when paper is stopped and pressured is Regi-Loop.
– To correct for registration and skew when the degree of skew varies from sheet to sheet,
increase the Regi-Loop value to increase pressure on the Lead Edge (LE) of the paper.
Increasing the value too much may cause unintended folds or scratches on the Lead Edge
paper.
– In hot and humid environments, decrease the Regi-Loop value to lower the pressure on
the Lead Edge of light weight paper to avoid ripping the paper.
• This feature is accessed from Machine Status→Tools→Setup & Adjustment→Custom Paper
Settings. Select the desired Custom Paper→Change Settings→Adjust Regi-Loop→Change
Settings.
• Based on the output, increase or decrease the Regi-Loop in increments of 0.3 mm. After each
incremental adjustment, run test prints and evaluate the output to determine if additional
adjustments are required.
• If feeding paper from tray 1, 2 or 3 and repeated Adjust Regi-Loop adjustments do not make
any improvements in a registration problem, return the Adjust Regi-Loop value to its default
setting.
4. Change the Adjust Fuser Speed setting.
• This feature is used to adjust the fusing speed to improve print quality when the image is
distorted (stretched or shrunk).
257
