15 Security
136 Xerox WorkCentre 4260 Series System Administration Guide
NOTE: If the Primary Domain Controller to which the users are to be authenticated
resides on a different subnet from the machine, select the Optional Information
checkbox and enter the IP address or Host Name of the Primary Domain Controller.
This is done because the SMB broadcast cannot get through a router unless the
router is configured to allow it. Entering the IP address or Host Name will allow the
authentication request through the router.
12. Enter your Backup Domain information in the [Additional Information] area.
13. Select the [Always prompt for logoff after each Scan job] option, in the [Logoff
Reminder] area, if you want to enable this service.
14. Click on the [Apply] button to accept the changes.
If prompted, enter the Administrator’s User ID [admin] and Password [1111], and
click on [Login].
15. Follow the steps in Verify that LDAP Authentication is enabled at the machine on
page 137 to check that you have setup authentication correctly.
Configure Network Authentication - LDAP
Authentication for LDAP requires the LDAP server information to be configured on the
machine. For instructions, see Chapter 8, Create a Local Address Book on page 88.
Procedure
1. At Your Workstation, open the web browser, enter the TCP/IP Address of the machine
into the Address bar.
2. Press [Enter].
3. Click on the [Properties] tab.
4. Click on the [Security] link.
5. Click on the [Authentication] link.
6. Click on the [Authentication] link.
7. Select the [Require Network Authentication] option.
8. To allow guests to access the machine, select the [Allow Guest Access] option and
enter the required [Passcode] for the guest account.
NOTE: You cannot leave the Passcode blank.
9. Select the [LDAP] option as Authentication Type.
10. Select the [Always prompt for logoff after each Scan job] option, in the Logoff
Reminder area, if you want to enable this service.
11. Click on the [Apply] button to accept the changes.
If prompted, enter the Administrator’s User ID [admin] and Password [1111], and
click on [Login].
12. Click on [OK].
13. Follow the steps below to check that you have setup authentication correctly.
