TCP/IP
Xerox WorkCentre 4260 Series System Administration Guide 17
23. Tou ch [Close] three times.
Configure TCP/IP Settings using CentreWare Internet Services
IPv4
1. At your Workstation, open the Web browser and enter the TCP/IP Address of the
machine in the Address bar.
2. Press [Enter].
3. Click on the [Properties] tab.
4. Click on the [Connectivity] link.
5. Click on the [Protocols] link.
6. Select [TCP/IP] from the directory tree.
7. Ensure that [IPv4] is selected. The Protocol will show as [Enabled].
NOTE: If you deselect the Protocol Enabled checkbox you will not be able to access
Internet Services. TCP/IP must then be enabled from the device's user interface.
8. Enter a unique [Host Name] for your machine.
9. Select the desired method for obtaining a dynamic IP address from the [IP Address
Resolution] drop down list or select [Static] to give the machine a static IP address.
10. If [Static] has been selected, type the IP addresses that apply in [Machine IP
Address], [Subnet Mask], and [Gateway Address].
NOTE: If BOOTP or DHCP address resolution mode is selected, you cannot change the IP
address, Subnet Mask, or default gateway. If RARP address resolution mode is selected, you
cannot change the IP address. Select Static if you wish to disable dynamic addressing.
Domain Name
11. Enter a valid [Domain Name].
DNS Configuration
12. Enter an IP address for the [Preferred DNS Server]. Enter an IP address for
[Alternate DNS Servers 1] and [2].
13. Check the box to enable [Dynamic DNS Registration].
NOTE: If your DNS Server does not support dynamic updates there is no need to enable
DDNS.
Zero-Configuration Networking
14. Select the [Self Assigned Address] enabled box to allow the machine to assign itself
an IP address of 169.254.x.x. This is useful in situations where the device cannot
connect to the DHCP server to obtain an IP address.
15. Select the [Multicast DNS] enabled box if you want to enable the device to perform
DNS queries over IP Multicast. This is essential for the Apple Rendezvous protocol to
map a host name to an IP address, used to advertise the services of the device.
