5.1 Selecting aΣ -Series Servo
215
SGDA-jjjj
SGDA-jjjjP
from previous page (A)
4) Determine applicable motor
see Note...
below
Type SGM
Type SGMP
Type SGM /
Type SGMP
?
End Servopack selection
Note The applicable motor type (SGM/SGMP) can be changed by setting the user constants.
5.1.3 Selecting a Digital Operator
1) The following two types of Digital Operator are available.
The two types cannot be used simultaneously. However, it is convenient to prepare both
types and use whichever suits the circumstances.
Each type differs in shape but the operating functions are identical.
JUSP-OP03A (Mount Type)
• Use attached to the top of the
Servopack front face.
JUSP-OP02A-1 (Hand-held Type)
• Use held in the hand while connected
with the 1 m cable supplied.
5
To Next Page
