5.3 Servopack Ratings and Specifications
This section presents tables of SGDA Servopack ratings and specifications separately
for speed/torque control and for position control.
5.3.1 Ratings and Specifications 235........................................
5.3.2 Overload Characteristics 240.........................................
5.3.3 Starting Time and Stopping Time 241..................................
5.3.4 Load Inertia 241.....................................................
5.3.5 Overhanging Loads 244..............................................
5.3.6 In-rush Current and Power Loss 245...................................
5.3.1 Ratings and Specifications
1) The ratings and specifications of the SGDA Servopack are shown below. Refer to them
as required when selecting a Servopack.
Refer to the specifications listed for combination with the appropriate type of Servomotor.
2) Ratings and Specifications of SGDA Servopack for Speed/Torque
Control
Voltage 200 VAC 100 VAC
SGDA Servopack A3AS A5AS 01AS 02AS 04AS 08AS A3BS A5BS 01BS 02BS 03BS
Max. Applicable Motor Capacity
W (HP)
30
(0.04)
50
(0.07)
100
(0.13)
200
(0.27)
400
(0.53)
750
(1.01)
30
(0.04)
50
(0.07)
100
(0.13)
200
(0.27)
300
(0.40)
Combined
S ifi
Motor
Type
A3Aj A5Aj 01Aj 02Aj 04Aj 08Aj A3Bj A5Bj 01Bj 02Bj 03Bj
Specifica-
tions
Motor Ca-
pacity W
(HP)
30
(0.04)
50
(0.07)
100
(0.13)
200
(0.27)
400
(0.53)
750
(1.01)
30
(0.04)
50
(0.07)
100
(0.13)
200
(0.27)
300
(0.40)
Rated/
Max. Mo-
tor Speed
3000/4500 r/min 3000/4500 r/min
Applicable
encoder
Incremental encoder 2048 P/R, absolute encoder 1024 P/R
Combined
Specifica-
tions
Allowable
Load Iner-
tia*
1
J
L
kg¡m
2
¢
10
−4
(oz¡in¡s
2
¢
10
−3
)
0.63
(8.80)
0.78
(11.0)
1.20
(17.0)
3.69
(52.2)
3.82
(54.1)
13.4
(189)
0.63
(8.80)
0.78
(11.0)
1.20
(17.0)
3.69
(52.2)
3.82
(54.1)
Combined
Specifica-
ti
Continuous Output
Current
0.42 0.6 0.87 2.0 2.6 4.4 0.63 0.90 2.2 2.7 3.7
p
tions
Max. Output Current 1.3 1.9 2.8 6.0 8.0 13.9 2.0 2.9 7.1 8.4 14.8
5
