YASKAWA SGDA series User Manual

SERVO SELECTION AND DATA SHEETS
5.6.7 1CN Connector
326
5.6.7 1CN Connector
1) This connector is required to connect the host controller to 1CN on the Servopack.
• Connector
Pin #1
Pin # 19
2.54(0.10)
1.27(0.05)
2.3(0.09)
5.1(0.20)
1.27
(0.05)
(0.50)
(0.11)
(0.26)
(0.76)
(0.36)
(0.30)
Units: mm (inches)
Connector Type A B C
10136-3000VE 21.59 (0.85) 27.8 (1.09) 32.2 (1.27)
5
