SERVO SELECTION AND DATA SHEETS
5.3.2Overload Characteristics
240
5.3.2 Overload Characteristics
The Servopack has a built-in overload protective function to protect the Servopack and Ser-
vomotor from overload. Therefore, the Servopack allowable power is limited by the overload
protective function, as shown below.
The overload detection level is quoted under hot start conditions at a motor ambient temper-
ature of 40°C.
TERMS
Hot Start
Indicates that both Servopack and Servomotor have run long enough at rated load to be
thermally saturated.
5
