Yealink SIP-T33P Administrator's Guide

Security Features
120
Default
0
Supported
Devices
T57W, T54W, T53W, T53, T48U, T46U, T43U, T42U, T48S, T46S, T42S, T41S, T33P, T33G, T31P,
T31G, T31, T30P, T30, T27G and CP920
Web UI
Settings > Auto Provision > Self-Define RSA Pri Key
Parameter
static.auto_provision.rsa_pri_key.delete <y0000000000xx>.cfg
Description
It deletes the self-define RSA private key file.
Permitted
Values
http://localhost/all
Default
Blank
Supported
Devices
T57W, T54W, T53W, T53, T48U, T46U, T43U, T42U, T48S, T46S, T42S, T41S, T33P, T33G, T31P,
T31G, T31, T30P, T30, T27G and CP920
[1]
X is an activation code ID. X=1-50.
[2]
If you change this parameter, the phone will reboot to make the change take effect.
Incoming Network Signaling Validation
Yealink phones support the following three optional levels of security for validating incoming network signaling:
l
Source IP address validation: ensure the request is received from an IP address of a server belonging to the set
of target SIP servers.
l
Digest authentication: challenge requests with digest authentication using the local credentials for the asso-
ciated registered account.
l
Source IP address validation and digest authentication: apply both of the above methods.
Topic
Incoming Network Signaling Validation Configuration
Incoming Network Signaling Validation Configuration
The following table lists the parameters you can use to configure the incoming network signaling validation.
Parameter
sip.request_validation.source.list <y0000000000xx>.cfg
Description
It configures the name of the request method for which source IP address validation will be applied.
Example:
sip.request_validation.source.list = INVITE, NOTIFY
Permitted
Values
INVITE, ACK, BYE, REGISTER, CANCEL, OPTIONS, INFO, MESSAGE, SUBSCRIBE, NOTIFY,
REFER, PRACK, UPDATE
Default
Blank
Parameter
sip.request_validation.digest.list <y0000000000xx>.cfg
Description
It configures the name of the request method for which digest authentication will be applied.
Example:
sip.request_validation.digest.list = INVITE, SUBSCRIBE
Permitted
Values
INVITE, ACK, BYE, REGISTER, CANCEL, OPTIONS, INFO, MESSAGE, SUBSCRIBE, NOTIFY,
REFER, PRACK, UPDATE

Yealink SIP-T33P Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Operating system installed	Linux
Lines quantity	4 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	4
Volume control	Buttons
Number of function keys	5
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, PLC, VAD, iLBC
Security algorithms	AES, HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-9 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	3 W
Power consumption (Power over Ethernet (PoE))	5 W
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	186 mm
Width	212 mm
Height	146 mm
