Yealink SIP-T33P Administrator's Guide

Troubleshooting Solutions
564
Logo Issues
Why does the IP phone use DOB format logo file instead of popular
BMP, JPG and so on?
The IP phone only uses logo file in DOB format, as the DOB format file has a high compression ratio (the size of the
uncompressed file compared to that of the compressed file) and can be stored in smaller space. Tools for con-
verting BMP format to DOB format are available.
Power and Startup Issues
Both PoE cable and power adapter is connected to the phone
The phones use the PoE preferentially.
The power LED indicator has no lights
If no lights appear on the IP phone when it is powered up, do one of the following:
l Reboot your device.
l Replace the power adapter.
The Phone screen is black
If the power LED indicator is on, the keypad is usable but the phone screen is black, please reboot your IP phone.
The IP phone always displays the Yealink logo
If your IP phone does not boot, check if the provisioning server is accessible on the network and a valid software
firmware and valid configuration files are available. Try to use recovery mode to get your phone ready. For more
information on recovery mode, refer to Recovery Mode on Yealink phones.
Other Issues
The difference among user name, register name, and display name
Both user name and register name are defined by the server. User name identifies the account, while register name
matched with a password is for authentication purposes. The display name is the caller ID that will be displayed on
the callee’s phone LCD screen. Server configurations may override the local ones.
On code and off code
They are codes that the IP phone sends to the server when a certain action takes place. On code is used to activate
a feature on the server side, while off code is used to deactivate a feature on the server side.

Yealink SIP-T33P Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Operating system installed	Linux
Lines quantity	4 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	4
Volume control	Buttons
Number of function keys	5
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, PLC, VAD, iLBC
Security algorithms	AES, HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-9 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	3 W
Power consumption (Power over Ethernet (PoE))	5 W
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	186 mm
Width	212 mm
Height	146 mm
