Yealink SIP-T33P Administrator's Guide

Administrator’s Guide for SIP-T2 /T3 /T4 /T5 /CP920 IP Phones
229
Custom Logo Configuration
Example: Setting a Custom Logo Display
Custom Logo Picture Limit
The following table lists the supported logo picture format and resolution for each phone model.
Phone Model
Logo File
Format
Resolution
T42U/T42S/T42G/T41P/T41S/T31P/T31G/T31/T30P/T30
.dob
<=192*64 2 gray scale
T53W/T53/T43U <=360*160 2 gray scale
T27G <=240*120 2 gray scale
T40P/T40G/T23P/T23G/T21(P) E2/T19(P) E2 <=132*64 2 gray scale
CP920 <=248*120 2 gray scale
Note: Before uploading your custom logo to phones, ensure your logo file is correctly formatted.
Customizing a Logo Picture
Yealink phones only support the *.dob format logo picture. Yealink provides PictureExDemo tool to convert *.bmp
format to *.dob format. You can ask the distributor or Yealink FAE for the PictureExDemo tool.
Procedure
1.
Double click the PictureExDemo.exe.
2. Click Add button to open a *.bmp file.
You can repeat step 2 to add multiple original picture files.
3. Click the Convert button.

Yealink SIP-T33P Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Wall mountable	Yes
Operating system installed	Linux
Lines quantity	4 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	4
Volume control	Buttons
Number of function keys	5
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Voice codecs	AGC, AJB, CNG, G.711a, G.711u, G.722, G.723.1, G.726, G.729, G.729A, PLC, VAD, iLBC
Security algorithms	AES, HTTPS
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-9 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	3 W
Power consumption (Power over Ethernet (PoE))	5 W
Number of handles included	1 pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	186 mm
Width	212 mm
Height	146 mm
