Administrator’s Guide for SIP-T5 Series Smart Media Phones
794
session.
In the INVITE request:
The IP address of User A is inserted in
the Request-URI field.
User C is identified as the call session
initiator in the From field.
A unique numeric identifier is
assigned to the call and is inserted in
the Call-ID field.
The transaction number within a
single call leg is identified in the CSeq
field.
The media capability User C is ready
to receive is specified.
The port on which User A is prepared
to receive the RTP data is specified.
INVITE—Proxy Server to User A
The proxy server maps the SIP URI in the To
field to User A. The proxy server sends the
INVITE message to User A.
180 Ringing—User A to Proxy
Server
User A sends a SIP 180 Ringing response to
the proxy server. The 180 Ringing response
indicates that the user is being alerted.
180 Ringing—Proxy Server to
User C
The proxy server forwards the 180 Ringing
response to User C. User C hears the
ring-back tone indicating that User A is
being alerted.
INVITE—User A to Proxy Server
User A sends a mid-call INVITE request to
the proxy server with new SDP session
parameters, which are used to place the call
on hold.
INVITE—Proxy Server to User B
The proxy server forwards the mid-call
INVITE message to User B.
200 OK—User B to Proxy Server
User B sends a 200 OK to the proxy server.
The 200 OK response indicates that the
INVITE was successfully processed.
200 OK—Proxy Server to User A
The proxy server forwards the 200 OK
response to User A. The 200 OK response
notifies User B is successfully placed on
