Yealink VC400 Administrator's Guide

Administrator’s Guide for Yealink Video Conferencing Systems
178
2. Select Enabled from the pull-down list of Hide IP Address.
3. Click Confirm to accept the change.
Hiding Menu Logo
When the system is idle, a Yealink logo is shown on the display device. You can hide the Yealink
logo as needed to achieve the best video effects.
Parameter of hiding menu logo on the system is described below:
Parameter
Description
Configuration Method
Hide Menu Logo
Enables or disables the system to
hide Yealink logo on the idle screen.
Default: Disabled
Web User Interface
To enable the hiding menu logo feature via web user interface:
1. Click on Setting->General.
2. Select the Enabled from the pull-down lists of Hide Menu Logo.

Yealink VC400 Specifications

General

Optical zoom	18 x
White balance	Auto, Indoor, Outdoor
Focus adjustment	Auto
Video codecs	H.264, H.264, H.263
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.711a, G.722
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
ITU-supported standards	H.323
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
Power consumption (max)	30 W

Weight and Dimensions

Depth	183 mm
Width	330 mm
Height	40 mm
