Yealink VC400 Administrator's Guide

Configuring Network
65
3. Enter the desired time interval in the Packet Interval (1-3600s) field.
4. Click Confirm to accept the change.
A dialog box pops up to prompt that the settings will take effect after a reboot.
5. Click Confirm to reboot the system immediately.
To configure LLDP via the remote control:
1. Select Menu->Advanced (default password: 0000) ->Advanced Network.
2. In the LLDP block, check the Active checkbox.
3. Enter the desired value in the Packet Interval (1-3600s) field.
4. Press the Save soft key to accept the change.
The display device prompts “Reboot now?”.
5. Select OK to reboot the system immediately.
Manual Configuration for VLAN
VLAN is disabled on systems by default. You can configure VLAN manually. Before configuring
VLAN on the systems, you need to obtain the VLAN ID from your network administrator.
Parameters of manual VLAN on the system are described below.
Parameter
Description
Configuration Method
Internet
Port->Active
Enables or disables VLAN for the
Internet (WAN) port.
Default: Disabled
Note: If you change this parameter,
the system will reboot to make the
Remote Control
Web User Interface

Yealink VC400 Specifications

General

Optical zoom	18 x
White balance	Auto, Indoor, Outdoor
Focus adjustment	Auto
Video codecs	H.264, H.264, H.263
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.711a, G.722
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
ITU-supported standards	H.323
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
Power consumption (max)	30 W

Weight and Dimensions

Depth	183 mm
Width	330 mm
Height	40 mm
