Yealink VC400 Administrator's Guide

Administrator’s Guide for Yealink Video Conferencing Systems
200
Mix Sending
Content sharing allows users to share content with other conference participants during a call.
When a PC is connected to the PC port on the VC400/VC120 Codec, the display device can
display both the camera video and the shared content. The content sharing feature is very useful
in the conference scenario in which content sharing is needed (e.g., a slide or a flash).
During a conference call, the far site may not support receiving shared content. In this case, you
can enable mix sending feature on the system. Mix sending feature allows the sender to
compound multiple video streams (local image+shared content) to one video stream, and then
send it to the far site.
The mix sending parameter on the system is described below.
Parameter
Description
Configuration Method
Mix
Enables or disables the mix sending
feature on the system.
Default: Enabled
Web User Interface
To configure mix sending via web user interface:
1. Click on Setting->Video & Audio.
2. In the Presentation block, select the desired value from the pull-down list of Mix.
3. Click Confirm to accept the change.

Yealink VC400 Specifications

General

Optical zoom	18 x
White balance	Auto, Indoor, Outdoor
Focus adjustment	Auto
Video codecs	H.264, H.264, H.263
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.711a, G.722
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
ITU-supported standards	H.323
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
Power consumption (max)	30 W

Weight and Dimensions

Depth	183 mm
Width	330 mm
Height	40 mm
