Yealink VC400 Administrator's Guide

Administrator’s Guide for Yealink Video Conferencing Systems
28
Icon
Description
Volume is 0
A USB flash drive is inserted to the port on the
VC400 Codec
Record a video
Local contact
Conference contact
Yealink Cloud contact or YMS contact
V
Permanent Virtual Meeting Room
Conference call
Dialed calls (H.323 account/SIP account/IP Call)
Dialed calls (Cloud platform)
Received calls (H.323 account/SIP account/IP
Call)
Received calls (Cloud platform)
Missed calls (H.323 account/SIP account/IP Call)
Missed calls (Cloud platform)
PC/Mobile mode (when a PC or mobile device
is connected to the VCP41)
LED Instructions
Indicator LED on the VC400/VC120 Codec:
LED Status
Description
Solid green
The VC400/VC120 Codec is powered on.
The VC400/VC120 Codec is upgrading firmware.
Solid red
The VC400/VC120 Codec is in sleep mode.
Solid orange
System exception (e.g., network unavailable, update failure).
Off
The VC400/VC120 Codec is powered off, is not connected
to the power adapter.

Yealink VC400 Specifications

General

Optical zoom	18 x
White balance	Auto, Indoor, Outdoor
Focus adjustment	Auto
Video codecs	H.264, H.264, H.263
Supported video modes	1080p
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.711a, G.722
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
ITU-supported standards	H.323
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
Power consumption (max)	30 W

Weight and Dimensions

Depth	183 mm
Width	330 mm
Height	40 mm
