10. Other Functions
10.1 Detailed Display
Select the desired parameter code to display the detailed operation data (see Table 10.1,
“Parameter Codes for Detailed Operation Data”.
NOTE
Refer to Section 7.8, “Setting Display Item”, for parameter code “A00”.
Table 10.1 Parameter Codes for Detailed Operation Data
Code Item
Engineering
unit
Code Item
Engineering
unit
A00 Selection
of display
items
0 Oxygen concentration A50 Span correction ratio 0 %
1 Oxygen analyzer (0.0) A51 Span correction ratio 1 %
2 Oxygen analyzer (0.0) A52 Span correction ratio 2 %
3 Analog output selected A53 Span correction ratio 3 %
A01 Oxygen concentration % O
2
A54 Span correction ratio 4 %
A02 Humidity %H
2
O A55 Span correction ratio 5 %
A03 Mixing ratio kg/kg A56 Span correction ratio 6 %
A04 Relative humidity % A57 Span correction ratio 7 %
A05 Dew point °C A58 Span correction ratio 8 %
A06 Air ratio A59 Span correction ratio 9 %
A07 Cell temperature °C A60 Zero correction ratio 0 %
A08 Cold junction temperature °C A61 Zero correction ratio 1 %
A09 Meas. gas temperature °C A62 Zero correction ratio 2 %
A10 Amount of water vapor in exhaust gas % A63 Zero correction ratio 3 %
A11 Cell voltage mV A64 Zero correction ratio 4 %
A12 TC voltage mV A65 Zero correction ratio 5 %
A15 Cold junction voltage mV A66 Zero correction ratio 6 %
A16 Output current mA A67 Zero correction ratio 7 %
A20 Cell response time Seconds A68 Zero correction ratio 8 %
A21 Cell internal resistance Ω A69 Zero correction ratio 9 %
A22 Cell robustness A70 Calibration history 0 YY.MM.DD/
HH.MM
A23 Heater on-time ratio % A71 Calibration history 1 YY.MM.DD/
HH.MM
A24 Oxygen concentration (with time
constant)
% O
2
A72 Calibration history 2 YY.MM.DD/
HH.MM
A25 Humidity (with time constant) %H
2
O A73 Calibration history 3 YY.MM.DD/
HH.MM
A26 Mixing ratio (with time constant) kg/kg A74 Calibration history 4 YY.MM.DD/
HH.MM
A30 Max. oxygen concentration % O
2
A75 Calibration history 5 YY.MM.DD/
HH.MM
A31 Occurrence of maximum oxygen
concentration
YY.MM.DD/
HH.MM
A76 Calibration history 6 YY.MM.DD/
HH.MM
