<8. Detailed Data Setting>
8-10
IM 11M12A01-04E 11th Edition : Jul. 19, 2017-00
CAUTION
Even with alarms set, if “Not detected” has been set in the above alarm detection, no alarm is
issued. Be sure to set “Detected” in the above alarm detection if you use alarm features.
8.3.4 Default Values
When the analyzer is delivered, or if data are initialized, the default alarm set values are as
shown in Table 8.8.
Table 8.8 Alarm Setting Default Values
Set item Set value
Oxygen concentration high-high alarm setpoint 100% O
2
Oxygen concentration high alarm setpoint 100% O
2
Oxygen concentration low alarm setpoint 0% O
2
Oxygen concentration low-low alarm setpoint 0% O
2
Humidity high-high alarm setpoint 100% H
2
O
Humidity high alarm setpoint 100% H
2
O
Humidity low alarm setpoint 0% H
2
O
Humidity low-low alarm setpoint 0% H
2
O
Mixing ratio high-high alarm setpoint 1 kg/kg
Mixing ratio high alarm setpoint 1 kg/kg
Mixing ratio low alarm setpoint 0 kg/kg
Mixing ratio low-low alarm setpoint 0 kg/kg
Oxygen concentration alarm hysteresis 0.1% O
2
Humidity alarm hysteresis 0.1% H
2
O
Mixing ratio alarm hysteresis 0.001 kg/kg
Delayed alarm action 3 seconds
High-high alarm detection Not detected
High alarm detection Not detected
Low alarm detection Not detected
Low-low alarm detection Not detected
8.4 Output Contact Setup
8.4.1 Output Contact
Mechanical relays provide contact outputs. Be sure to observe relay contact ratings. (For details,
see Section 2.1, “General Specications.”) The following sets forth the operation mode of each
contact output. Output contact 1 you can select open or closed contact when the contact is
“operated”. For output contact 2, contact is closed. The relay for output contact 1 is energized
when its contacts are closed and vice versa. Accordingly, when no power is supplied to the
equipment, those contacts remain open. In addition, the relay for output contact 2 is energized
when the corresponding contact is open and de-energized when that contact is closed.
