YOKOGAWA ZR402G User Manual

<7. Startup>
7-9
IM 11M12A01-04E
7.6 Selection of Measurement Gas
Combustion gases contain moisture created by burning hydrogen in the fuel. If this moisture is
removed, the oxygen concentration might be higher than before. You can select whether the
oxygen concentration in a wet gas is to be measured directly, or compensated for its dry-gas
value before use. Use the parameter code “F02” to set the measurement gas. For details on the
parameter code, see Table 10.7 or Table 10.8, later in this manual.
Table 7.4 Setting Measurement Gas
Switch operation Display Description
> ∧
ENT
A01
Display after the password has been entered.
> ∧
ENT
F01
Touch the [∧] key to switch to Group F. If an unwanted alphabetic
character after F has been entered, continuously touch the [∧] key to
return to the original.
> ∧
ENT
F01
Touch the [>] key to move the position of the digit that is ashing to the
right.
> ∧
ENT
F02
Touch the [∧] key to change the numeric value to 2. If an unwanted
numeric value has been entered, continuously touch the [∧] key to return
to the original.
> ∧
ENT
0
Touch the [ENT] key for conrmation. If 0 (zero) is entered, the oxygen
concentration in a wet gas is already set. If the oxygen concentration in a
dry gas is to be entered, follow the steps below to set 1 (one).
> ∧
ENT
0
Continuously touch the [∧] key, and the position of the digit will change
from 1 to 0 to 1 to 0. Release the [ENT] key when 1 (one) is displayed.
> ∧
ENT
0
Touch the [ENT] key. The numeric value will ash.
> ∧
ENT
0
Touch the [ENT] key again to stop the value from ashing.
> ∧
ENT
F03
Touch the [ENT] key once again, and the display will change to the
parameter code selection panel.
> ∧
ENT Basic
panel
display
Touch the [>] key together with the [ENT] key to return to the basic panel
display. (This is not required if you proceed to make another setting.)
(The displayed numeric characters indicate the measurement gas
concentration.)
The symbol [ ] indicates that the key is being touched. Light characters indicates that the digits are ashing.
7.7 Output Range Setting
This section sets forth analog output range settings. For details, consult Section 8.1,”Current
Output Settings,” later in this manual.
7.7.1 Oxygen Analyzer -Minimum Current (4 mA) and
Maximum Current (20 mA) Settings
Use the parameter codes “C11” to set the oxygen concentration at 4 mA and “C12” to set the
oxygen concentration at 20 mA. The following shows where 10% O
2
is set at 4 mA and 20% O
2
at 20 mA.
11th Edition : Jul. 19, 2017-00
