<8. Detailed Data Setting>
8-12
IM 11M12A01-04E 11th Edition : Jul. 19, 2017-00
8.4.3 Default Values
When the analyzer is delivered, or if data are initialized, output contacts are by default as shown
in Table 8.11.
Table 8.11 Output Contact Default Settings
Item Output contact 1 Output contact 2
High-high alarm
High alarm
Low alarm
Low-low alarm
Error O
Warm-up O
Output range change
Calibration
Maintenance O
High limit temperature alarm
Calibration gas pressure
decrease
Unburnt gas detection
Operating contact status Open Closed (xed)
O: Present
NOTE
The above blank boxes indicate the items have been set off.
8.5 Input Contact Settings
8.5.1 Input Contact Functions
The converter input contacts execute set functions by accepting a remote (contact) signal. Table
8.12 shows the functions executed by a remote contact signal.
Table 8.12 Input Contact Functions
Set item Function
Calibration gas pressure
decrease
While a contact signal is on, neither semi-automatic nor automatic calibrations
can be made.
Measuring range change While contact input is on, the analog output range is switched to 0-25% O
2
.
Calibration start If a contact signal is applied, semi-automatic calibration starts (only if the semi-
automatic or automatic mode has been setup). Contact signal must be applied
for at least one second. Even though a continuous contact signal is applied, a
second calibration cannot be made. If you want to make a second calibration,
turn the contact signal off and then back on.
Unburnt gas detection If a contact signal is on, the heater power will be switched off. (An one-to
11-second time interval single-output signal is available as a contact signal.) If
this operation starts, the sensor temperature decreases and an error occurs. To
restore it to normal, turn the power off and then back on, or reset the analyzer.
