<7. Startup>
7-6
IM 11M12A01-04E
7.4.4 Selecting Parameter Codes
Switch operation Display Description
> ∧
ENT
A01
Password has been entered and the parameter code selection display
has appeared.
Character A is ashing, indicating that character A can be changed.
> ∧
ENT
A01
If you touch the [>] key once, the position of the digit that is ashing will
move to the right.
This allows you to change 0.
> ∧
ENT
A01
Touch the [>] key again to move the position of the digit that is ashing to
the right one more digit. This enables you to change numeric character 1.
> ∧
ENT
A01
Touch the [>] key again to return the position of the digit that is ashing
to A. Continuously touch the [>] key, and the position of the digit that is
ashing will move continuously to the right.
> ∧
ENT
b01
If you touch the [∧] key once, character A will change to B.
> ∧
ENT
C01
Touch the [∧] key once to change to C.
> ∧
ENT
d01
Continuously touch the [∧] key, and the value of the digit that is ashing
will increase continuously, from D to E to F to G to A. Numeric values will
change from 0 to 1 to 2 to 3 … to 8 to 9 and back to 0. However, numbers
that are not present in the parameter codes will be skipped. Each digit is
changed independently. Even though a low-order digit changes from 9 to
0, a high-order digit will not be carried.
> ∧
ENT Set
Value
After you select the desired character, touch the [ENT] key. The set data
will be displayed.
The symbol [ ] indicates that the key is being touched. Light characters indicates that the digits are ashing.
7.4.5 Changing Set Values
(1) Selecting numeric values from among preset values
Switch operation Display Description
> ∧
ENT
0
The set value is displayed after the parameter code selection. An
example of how to select either 0, 1, or 2 as the set value is given below.
(The currently set value is 0.)
> ∧
ENT
1
Touch the [∧] key once to change the current value from 0 to 1.
> ∧
ENT
2
Touch the [∧] key again to change to the numeric value 2.
> ∧
ENT
0
If you touch the [∧] key again, the numeric value will return to 0.
Continuously touch the [∧] key, and the numeric values will change
continuously.
> ∧
ENT
C01
Display the desired numeric value and touch the [ENT] key.
The display will then return to the parameter code selection
11th Edition : Jul. 19, 2017-00
