ABB ACSM1 Series User Manual

Contents of the manual
The manual consists of the following chapters:
 Introduction describes how to configure ABB Drives function blocks for Siemens PLC’s.
 Drive configuration describes how to configure the drive for PROFIBUS DP or PROFINET
control based on ABB specific drives library ABB_DRIVE_LIB.
 SIMATIC Manager provides the examples to configure S7-300 series PLC.
 TIA portal provides the examples to configure S7-300 and S7-1200 series PLC.
Related documents
A list of related manuals is printed on the inside of the front cover.
SIMATIC Manager/TIA portal with ABB drives and PROFIBUS
module setup
The figure below shows an example of SIMATIC Manager/TIA portal with ABB drives and PROFIBUS
module setup.
SIMATIC Manager/TIA
portal
Siemens PLC
ETHERN
ET or
serial
connecti
on
ABB drives
ABB
PROFIBUS
modules

ABB ACSM1 Series Specifications

General

Brand	ABB
Model	ACSM1 Series
Category	Controller
Language	English
