ACS800 Minimum required parameter settings for PROFINET
The minimum required parameter settings based on factory default settings.
Parameter
Description
Setting
Comment
98.02
COMM.
MODULE LINK
FIELDBUS
Activates fieldbus module
98.07
COMM
PROFILE
ABB DRIVES
Communication profile ABB drives
51.01
FBA A ype
Ethernet
Filedbus type
51.02
Protocol/Profile
PNIO ABB Pro (11)
Communication profile ABB drives
51.04
IP Configuration
Static (0)
-
51.05 ...
51.08
IP address
192.xxx.xx.xx or any
other required IP
address.
-
51.09
Subnet CDR
24
24 For subnet mask 255.255.255.0
51.27
FBA PAR
REFRESH
REFRESH
Updates fieldbus settings (groups 51 to 55)
10.01
EXT 1
STRT/STP/DIR
COMM.CW
Fieldbus interface as source for start and
stop
11.03
EXT REF1
SELECT
COMM.REF
Fieldbus interface as source for speed
reference
16.04
FAULT RESET
SEL
COMM.CW
Fieldbus interface as source for fault reset
(11.05)
EXT REF1
MAXIMUM
[Scale max]
Max speed/frequency scaling value (used in
function block/visualization input
SPEED_REF_MAX). Must be less or equal
to drive parameter max speed/frequency.
